Nrog lub peev xwm los thauj thiab pov tseg cov ntaub ntawv hnyav xws li xuab zeb, pob zeb, thee, thiab lwm yam kev tsim kho lossis cov khoom siv, peb lub tsheb thauj khoom rov qab ua kom yooj yim dua thiab nrawm dua. Cov qauv tsim tshwj xeeb tso cai rau qhov siab ntawm lub thawv pov tseg kom tso cov khoom tawm ntawm lub nraub qaum kom zoo. Cov tsheb thauj khoom no feem ntau siv rau hauv kev tsim kho, tsuas, thiab lwm yam kev lag luam uas yuav tsum muaj kev thauj mus los ntawm cov khoom hnyav.
Ntsiab nta
Kev siv ntau yam:Nrog lub tsheb thauj khoom rov qab, koj tuaj yeem yooj yim thauj cov tshuab txiav, cov khoom siv me me, thiab cov khoom hnyav mus thiab los ntawm koj qhov chaw ua haujlwm.
Muaj peev xwm:Peb cov tsheb thauj khoom tau tsim nrog sab siab los tswj cov khoom loj dua nrog cov ntaub ntawv ntxhib, ua kom cov khoom siv tau zoo dua thiab ua haujlwm zoo.
Customizable Design:Tailor lub trailer raws li koj xav tau, nrog rau kev xaiv rau 2, 3, 4, 5, lossis 6 axles. Xaiv ntawm U-puab lossis teb-zoo li tus (lub kaum sab xis) pob tseg trailer kom tau raws li koj cov kev xav tau tshwj xeeb.
Yog xav paub ntxiv txog peb lub tsheb thauj khoom rov qab lossis thov kom muaj kev cai hais, thov hu rau peb pab pawg muag khoom ntawm WhatsApp:+8615806691798.
Specifications
| REAR DUMP SEMI TRAILER - U-SHAPE | |
|---|---|
| Tare luj | 8 730kg |
| Loj | 8870mm * 2500mm * 3500mm |
| Chassis | Heavy luag hauj lwm thiab ntxiv durability tsim kuv beam; opting rau T700, welded los ntawm tsis siv neeg Submerged-Arc txheej txheem. Sab saum toj phaj 14mm .qab phaj 8mm .middle phaj 14mm .siab: 500mm |
| Qag | 3 faus 13t |
| Kev ncua | Mechanical suspension |
| Nplooj caij nplooj ntoos hlav | Nplooj caij nplooj ntoos hlav 90mm * 11mm * 10pcs |
| Lub tog raj kheej | TIAB SA 196 |
| Pem teb | Pem teb 4 hli sab phab ntsa 3 hli |
| Lub log | 11.00R20 18PR daim duab peb sab hom 13 |
| Lub log rim | 8.0-20 Lub npe zoo dua 13 |
| Kingpin | 3.5 '' bolt-hauv huab tais tus pin |
| tsaws iav | SAF hom ob-ceev, phau ntawv khiav haujlwm, hnyav tsaws iav 28T |
| ABS | 4S/2M |
| Braking system | WABCO RE6 relay valve; T30/30 caij nplooj ntoos hlav nres chamber; 40L cua tso tsheb hlau luam |
| Spare trie cab kuj | 1 pcs |
| Tool lub thawv | 1 pcs |
| Kev pleev xim | Ua kom tiav chassis xuab zeb blasting los ntxuav xeb, 1coat ntawm anticorrosive prime, 2coats ntawm zaum kawg xim |
| Khoom siv | Ib tug ncej wrench |
